Warmset 12V Extra-Low Voltage (ELV) Marine, Wetroom / Walk-In Shower Heating Mat

Warmset 12V Extra-Low Voltage (ELV) Marine, Wetroom / Walk-In Shower Heating Mat

Because of its 12V extra-low voltage (ELV) system, the heating mat is suitable for installation under a shower tray or in other wet areas.
Consumes up to 30% less electricity compared to standard heating matts.
A highly efficient infrared heating element warms not only the air but also all surrounding surfaces.
Close spacing between heating elements (2.5–7 cm) ensures even floor heating (eliminates cold–hot–cold spots).
A 100% Italian patented product.
Safe to use – the mesh is fully earthed.
Very fast and easy installation.
Health-friendly – the system does not emit electromagnetic radiation.

Warmset Black 150W 12V Electric Underfloor Heating Mat

This electric underfloor heating mesh is designed to create efficient and comfortable heated floors. Warmset Black 150W 12V is a unique, patented infrared heating system with no direct equivalent on the market. The 150W element heats up quickly, warming both the floor surface and the room.
The mat thickness is only 3 mm (connection ends approx. 6 mm), making it suitable for installation under most floor coverings. It can be installed in levelling compound or tile adhesive.

Why the 12V System is Different

Warmset Black 150W 12V stands out with its extra-low 12 volt system, providing maximum safety even in direct contact with water.
Ideal for wetrooms, showers, SPA zones, pool areas, and any moisture-rich environment.
The low-voltage technology ensures both efficient, even heating and complete peace of mind—protected from electrical discharge even under extreme conditions.

Key Advantages

✔ Energy Efficient

Uses up to 30% less electricity compared to standard heating mats.
Maintenance-free system.

✔ Comfort Heating

The infrared heating element distributes heat evenly across surfaces while also warming the air.

✔ Even Heat Distribution

Heating wires spaced 2.5–7 cm apart prevent cold spots on the floor.

✔ Easy Installation

Simple to install with basic electrical knowledge.

✔ Invisible Heating

Hidden under the floor for a clean interior look.
Controlled by a small, unobtrusive thermostat.

✔ Universal Application

Suitable for kitchens, living rooms, bathrooms, bedrooms, and wetrooms.
Compatible with many floor finishes: tiles, laminate, vinyl, etc.

✔ Fully Adjustable

Works with thermostats that allow manual or programmable temperature control.

✔ Silent Operation

Produces no noise, suitable even for bedrooms or offices.

✔ Safe Design

Does not emit electromagnetic waves and includes full grounding.
Certified safe for domestic and commercial installations.

✔ High Quality

100% Italian, patented product with a 10-year warranty.
Certified: NEMKO, BEAB, UL, CE, NF, TUV, TCNA.

System Voltage: 12V Extra-Low Voltage (ELV) (transformer  12V AC not included)
Output: 150W
IP rating: 64
Heating Technology: Patented Infrared Carbon Element
Mat Thickness: 3 mm (connection ends approx. 6 mm)
Element Spacing: 2.5–7 cm
Installation Method: In tile adhesive or levelling compound
Suitable Areas: Wetrooms, showers, SPA zones, pool areas, bathrooms
Floor Finishes: Tiles, laminate, vinyl, engineered wood
Earthing: Fully earthed mesh
EMF Emissions: No electromagnetic radiation
Energy Consumption: Up to 30% lower vs standard mats
Certification: NEMKO, BEAB, UL, CE, NF, TÜV, TCNA
Warranty: 10 Years
Country of Manufacture: 100% Italian – Patented

Warmset Black Aluminium Heating Mat – Electrical Safety

The Warmset Black heating element is insulated with a high-quality polypropylene sheath, designed to withstand temperatures of up to 150 °C.

The heating mat is rated IP68, meaning it is fully protected against moisture and water exposure, making it suitable for installations in wet environments when installed correctly.

For additional safety, the heating mat includes protective grounding, ensuring any potential electrical fault is safely discharged. When installed in accordance with manufacturer instructions and electrical regulations, the system prevents electrical leakage and eliminates the risk of fire caused by electrical faults.

BS 7671 Compliance – Bathroom & Wetroom Installations

According to BS 7671 (IET Wiring Regulations), special safety requirements apply when installing electrical equipment in bathrooms and wetrooms.

Zone 0

(Inside the bath, shower tray, or walk-in shower floor area)

Only SELV (Separated Extra-Low Voltage) systems are permitted.

Maximum permitted voltage:

• 12V AC
• 30V DC

The power supply transformer must be installed outside Zones 0, 1, and 2.

For additional safety, BS 7671 recommends the use of DC systems or AC systems not exceeding 12V.

Compliance Statement

The Warmset 12V AC/DC heating mat is suitable for installation in Zone 0 when used with an appropriate SELV transformer located outside the restricted zones.

Recommended Transformer

Varilight YT210Z Transformer

• Output: 0–12V AC
• Power Rating: 0–210 VA (0–210 W)
• Suitable for SELV heating systems
• Ideal for 12V Warmset heating mats used in wetroom installations
